Large Capacity Rotary Sand Dryer Machine For Sawdust Convenient Operation

    Buy cheap Large Capacity Rotary Sand Dryer Machine For Sawdust Convenient Operation from wholesalers

    Buy cheap Large Capacity Rotary Sand Dryer Machine For Sawdust Convenient Operation from wholesalers
    • Buy cheap Large Capacity Rotary Sand Dryer Machine For Sawdust Convenient Operation from wholesalers

    Large Capacity Rotary Sand Dryer Machine For Sawdust Convenient Operation

    Ask Lasest Price
    Brand Name : SINCOLA
    Model Number : SS-625
    Certification : ISO CE BV
    Price : USD9700
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 20sets per week
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    Large Capacity Rotary Sand Dryer Machine For Sawdust Convenient Operation

    Wet sand coal rotary drum drying machine dryer machine for Sawdust


    Main parameters

    ParametersSS623SS625SS6210SS6220
    Drying capacity1-3 m3/h4-6 m3/h10-14 m3/h20-30 m3/h
    Diameter of drum2200mm2200mm2500mm2600mm
    Length1500mm2500mm2700mm3700mm
    Motor power4kw5.5kw4kw*25.5kw*2
    Reducer modelXWD-5XWD-5XWD-5XWD-5
    Speed of drum rotation4-10 r/min4-10 r/min4-10 r/min4-10 r/min
    Moisture of end products0.1%-0.8%0.1%-0.8%0.1%-0.8%0.1%-0.8%
    Max. temperature inside700-750℃700-750℃700-750℃700-750℃
    Outlet temperature30-60℃30-60℃30-60℃30-60℃
    Hot-blast Stove dimensions1.55m×1.3m×2.18m2.3m×2m×2.7m2.3m×2m×2.7m2.3m×2m×2.7m
    Furnace door450*550 mm450*550 mm450*550 mm450*550 mm
    Quicksand tubeφ165×1600 mmφ273×1800 mmφ300×1800 mmφ400×2000 mm
    Coal consumption7-10 kg/ per ton sand7-10 kg/ per ton sand7-10 kg/ per ton sand7-10 kg/ per ton sand

    Wet sand coal rotary drum drying machine dryer machine for Sawdust


    Brief Introduction

    Sand Rotary Dryer is also called the river sand dryer, sand dryer, quartz sand dryer. It is a kind of drying equipment to process a large amount of wet sand material, and it has reliable operation, strong adaptability and large capacity.

    Applications

    industrial small silica sand triple pass rotary drum dryer used rotary sand dryer price used for drying certain humidity range granular materials, such as
    1. casting sand which used in dry-mixed mortar and foundry industry
    2. small granular clay used in construction and cement industry
    3. small granular material in chemical industry which no chemical change, not afraid of heat and dust pollution
    such as coal, blue carbon, fly ash, sand, water slag, river sand, quartz sand, slag, clay etc.

    Features

    1) Three cylinder dryer is scientific and reasonable, efficient energy-saving materials. High thermal efficiency and energy-saving effect is remarkable.
    2) The machine adopts the material and hot air flow drying process with wide application range.More convenient installation, simple operation, reliable operation, high operation rate.
    3) The three cylinder has thermal insulation function with less heat loss,.High efficiency in energy saving greatly improve the working environment and working conditions.
    4) With variable frequency speed regulation, it can adjust the cylinder speed according to the water and the output requirements.The use of appropriate speed ensure that the next process meet the needs. Automatic temperature monitoring system makes the operation more convenient
