Customization Large hopper Electric Mini Concrete Shotcrete Pump
including vibrate machine
Detailed Description of Full hydraulic Mini Concrete Shotcrete
Pump:
SPB Full Hydraulic Mini Shotcrete Pump Machine
high efficiency: full hydraulic pumping technical, reliable
performance.
long spraying distance: 150m horizontally and 80m vertically.
continuously adjustable flux and accelerator adding volume.
low fitting consumption, long service life of wearing parts.
flexible movement, convenient operation and maintenance.
Technical specification of Piston wet shotcrete machine:
| Model | Unit | SPB6I | SPB8I |
| Capacity | m3/h | 6 | 8 |
| Max. aggregate size | mm | 15 | 15 |
| Fineness modulus | / | ≥2.5 | ≥2.5 |
| Delivery pipe | mm | DN100/DN80 | DN100/DN80 |
| Concrete slump | cm | 10~18 | 10~18 |
| Max. horizontally conveying dist. | m | 120 | 150 |
| Max. vertically conveying dist. | m | 50 | 80 |
| Main motor power | kw | 15 | 22 |
| Max. operating oil pressure | M pa | 12 | 19 |
| Max. output pressure | M pa | 5 | 8 |
| Feeding height | mm | 1100 | 1100 |
| Dimensions (L×W×H) | mm | 2990×1200×1140 | 2990×1200×1140 |
| Weight | kg | 1600 | 1600 |
Application of Full hydraulic Mini Concrete Shotcrete Pump
convey fine aggregate concrete and mortar for high buildings.
grout heat-insulated lightweight foamed cement, mortar floor
heating, and self leveling for ground architecture.
spray plain concrete and fiber concrete in engineering
construction.
convey and spray refractory and thermal insulation material.
spray afforestation soil in ecological environment construction.
pressure perfussion for foundation piles, back fill in over broken
tunnels, railway slope supporting, and disaster management.
FAQ
Anti Explosion Shotcrete Machine New Shotcrete Nozzle Dedusting
Shotcrete Machine
1. Q: Which model should we choose?
A: We have many models for your choice. Before suitable model is
recommended, please tell us the application, materials, output and
pressure you want.
2. Q: Can we have customized model?
A: Yes. We can make the customized machine according to your actual
requirements.
3. Q: Do I need to know technical skills to operate this machine?
A: No. This machine has no professional requirements for the
operator. However, we provide technical instruction for your
backup.
4.Q: What should we do if there are some problems with the machine?
A: You can refers to the Operate Instruction or contact us for
online instruction. Also, our engineers are available to service
overseas.
5.Q: What is the lead time?
A: 1 week for sample model, 2~3 weeks for customized model. It
depends for mass production.
6.Q: How about the package?
A: We have fumigation-free wooden case to protect the machine from
damage during the long-distance delivery.
7.Q :How should I pay for you if I place this order?
A: Generally, TT, 30% deposit 70% before shipment.
Our service:
- 24 hours on line service
- All after -sale service problem will be solved in 72 hours
- Accessories globally supply
- Lifetime technique support
- Engineer serve overseas available
