    High Output Industrial Rotary Dryer Rotary Drying Machine Belt Conveyor

    Ask Lasest Price
    Brand Name : SINCOLA
    Model Number : SS-625
    Certification : ISO CE BV
    Price : USD9700
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 20sets per week
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    High Output Industrial Rotary Dryer Rotary Drying Machine Belt Conveyor

    4.5’ rotary thermal sand dryer machine for all kinds of sand,frac, silica, foundry, construction


    This 4.5′ diameter rotary thermal sand drying system is available as a complete plant or individual pieces. It can be customized to meet your needs, but a typical drying system layout would include: feed bin, weigh conveyor, thermal rotary dryer with burner (natural gas, vaporized propane, light or heavy oil), discharge conveyor, cyclone, baghouse with ID fan, connecting ductwork, controls and a control house.


    This rotary thermal drying system can be designed as either portable or stationary. The dryer flights can be adjusted to maximize efficiency to accommodate all types of sand: frac, silica, foundry, construction, etc. Rotary thermal dryers are very robust when compared to other drying methods like horizontal fluidized bed dryer, vertical fluidized dryer, vertical tray dryer, spray dryer, or flash dryer.


    » Applications:

    Various sand: eg. River sand, sea sand, mining sand, molding sand, etc.

    Grain sizes: 0.075 to 10mm typicallyEnergy-efficient Rotary Sand Dryer Machine Upgraded Triple-pass design Special Offer 5% off

    » Output Capacity:

    3 t/h to 110 t/h

    Final moisture: ≤ 0.5%

    » Motor Power:

    4 Kw/h to 88 Kw/h

    » Drying Temperature:

    Max. 750 oC


    Main parameters

    ParametersSS623SS625SS6210SS6220
    Drying capacity1-3 m3/h4-6 m3/h10-14 m3/h20-30 m3/h
    Diameter of drum2200mm2200mm2500mm2600mm
    Length1500mm2500mm2700mm3700mm
    Motor power4kw5.5kw4kw*25.5kw*2
    Reducer modelXWD-5XWD-5XWD-5XWD-5
    Speed of drum rotation4-10 r/min4-10 r/min4-10 r/min4-10 r/min
    Moisture of end products0.1%-0.8%0.1%-0.8%0.1%-0.8%0.1%-0.8%
    Max. temperature inside700-750℃700-750℃700-750℃700-750℃
    Outlet temperature30-60℃30-60℃30-60℃30-60℃
    Hot-blast Stove dimensions1.55m×1.3m×2.18m2.3m×2m×2.7m2.3m×2m×2.7m2.3m×2m×2.7m
    Furnace door450*550 mm450*550 mm450*550 mm450*550 mm
    Quicksand tubeφ165×1600 mmφ273×1800 mmφ300×1800 mmφ400×2000 mm
    Coal consumption7-10 kg/ per ton sand7-10 kg/ per ton sand7-10 kg/ per ton sand7-10 kg/ per ton sand
